Circular Economy Ontology Network (CEON) - Plan Module
Metadata
- IRI
-
http://w3id.org/CEON/ontology/plan/ - Title
-
Circular Economy Ontology Network (CEON) - Plan Module
- Publisher
-
Onto-DESIDE
- Creator
-
Huanyu Li
- Contributor
-
Eva Blomqvist
- Date Created
-
2025-06-19
- Date Issued
-
2025-06-30
- Version Info
-
0.1
- Preferred Namespace Prefix
-
ceon-plan
- Description
-
The Plan module of CEON (Circular Economy Ontology Network).
- Covers Requirements
-
-
In addition to requirements covered by imported ODPs, covers the following requirements from Onto-DESIDE D3.1: T8-2
-
In addition to requirements covered by imported ODPs, covers the following requirements from Onto-DESIDE D3.2: T8-2
-
Overview
Connections between Plan module and Process ODP
The following diagram shows the connections between the Plan module the Process ODP.
Classes
Description c
| IRI |
http://w3id.org/CEON/ontology/plan/Description
|
|---|---|
| In Range Of | satisfiesPlan op |
| Super Class Of | Plan c |
Plan c
| IRI |
http://w3id.org/CEON/ontology/plan/Plan
|
|---|---|
| Sub Class Of | Description c |
| In Domain Of | hasPlanExecution op |
| Restriction | processODP:hasPart some Plan c |
Plan Execution c
| IRI |
http://w3id.org/CEON/ontology/plan/PlanExecution
|
|---|---|
| Sub Class Of | |
| In Domain Of | |
| In Range Of | hasPlanExecution op |
| Restriction |
|
Object Properties
follows execution op
| IRI |
http://w3id.org/CEON/ontology/plan/followsExecution
|
|---|---|
| Sub Property Of | processODP:isSettingFor |
| Domain | PlanExecution c |
has plan execution op
| IRI |
http://w3id.org/CEON/ontology/plan/hasPlanExecution
|
|---|---|
| Sub Property Of | topObjectProperty op |
| Domain | Plan c |
| Range | PlanExecution c |
precedes execution op
| IRI |
http://w3id.org/CEON/ontology/plan/precedesExecution
|
|---|---|
| Sub Property Of | processODP:isSettingFor |
| Domain | PlanExecution c |
satisfies plan op
| IRI |
http://w3id.org/CEON/ontology/plan/satisfiesPlan
|
|---|---|
| Sub Property Of | topObjectProperty op |
| Domain | processODP:Situation |
| Range | Description c |
has input op
| IRI |
http://w3id.org/CEON/ontology/processODP/hasInput
|
|---|
has output op
| IRI |
http://w3id.org/CEON/ontology/processODP/hasOutput
|
|---|
Datatype Properties
occurs at time dp
| IRI |
http://w3id.org/CEON/ontology/plan/occursAtTime
|
|---|---|
| Domain | PlanExecution c |
| Range | xsd:dateTime |
Namespaces
- :
-
http://w3id.org/CEON/ontology/plan/ - dcterms
-
http://purl.org/dc/terms/ - odp
-
http://www.ontologydesignpatterns.org/schemas/cpannotationschema.owl# - owl
-
http://www.w3.org/2002/07/owl# - processODP
-
http://w3id.org/CEON/ontology/processODP/ - prov
-
http://www.w3.org/ns/prov# - rdf
-
http://www.w3.org/1999/02/22-rdf-syntax-ns# - rdfs
-
http://www.w3.org/2000/01/rdf-schema# - vann
-
http://purl.org/vocab/vann/ - xsd
-
http://www.w3.org/2001/XMLSchema#
Legend
| c | Classes |
| op | Object Properties |
| dp | Datatype Properties |
