Circular Economy Ontology Network (CEON) - Product Module

Metadata

IRI: http://w3id.org/CEON/ontology/product/
Title: Circular Economy Ontology Network (CEON) - Product Module
Publisher: Onto-DESIDE
Creator: Huanyu Li
Contributor: Eva Blomqvist
Date Created: 2025-03-19
Date Issued: 2025-06-30
License: https://creativecommons.org/licenses/by/4.0/
Version Iri: http://w3id.org/CEON/ontology/product/0.5/
Version Info: 0.5
Prior Version: 0.4
Preferred Namespace Prefix: ceon-product
Preferred Namespace Uri: http://w3id.org/CEON/ontology/product/
Description: The Product module of CEON (Circular Economy Ontology Network).
Covers Requirements: In addition to requirements covered by imported ODPs, covers the following requirements from Onto-DESIDE D3.1: CVN-Resource-2, CVN-ResrouceType-4, C11-2, C12-1, C13-3, E2-1, T8-3.

In addition to requirements covered by imported ODPs, covers the following requirements from Onto-DESIDE D3.2: CE5-2, C11-2, C12-1, C13-3, E2-1, T8-3.

Overview

Figure 1: Ontology overview.

⛶

Connections between Product module and Resource ODP

The following diagram shows the connections between the Product module the Resource ODP.

Figure 2: Connections between the Product module the Resource ODP.

⛶

Classes

Actor ^c

IRI	`http://w3id.org/CEON/ontology/actorODP/Actor`

Resource Relation ^c

IRI	`http://w3id.org/CEON/ontology/actorODP/ResourceRelation`

Location ^c

IRI	`http://w3id.org/CEON/ontology/location/Location`
Super Class Of	AssemblyLocation ^c ManufactureLocation ^c OriginLocation ^c ProductionLocation ^c SupplierLocation ^c

Process ^c

IRI	`http://w3id.org/CEON/ontology/processODP/Process`

Assembly Location ^c

IRI	`http://w3id.org/CEON/ontology/product/AssemblyLocation`
Sub Class Of	http://w3id.org/CEON/ontology/location/Location ^c
In Domain Of	countryOfAssembly ^dp
In Range Of	hasAssemblyLocation ^op
Restriction	http://w3id.org/CEON/ontology/location/hasCity ^dp max 1 AssemblyLocation ^c http://w3id.org/CEON/ontology/location/hasPostalCode ^dp max 1 AssemblyLocation ^c http://w3id.org/CEON/ontology/location/hasStreetAddress ^dp max 1 AssemblyLocation ^c countryOfAssembly ^dp max 1 AssemblyLocation ^c

Compliance ^c

IRI	`http://w3id.org/CEON/ontology/product/Compliance`
In Domain Of	complianceWith ^op hasCertificate ^dp
In Range Of	hasCompliance ^op
Super Class Of	ISOCompliance ^c REACHCompliance ^c RoHSCompliance ^c

Composition ^c

IRI	`http://w3id.org/CEON/ontology/product/Composition`
Sub Class Of	actorODP:ResourceParticipation
In Domain Of	compositionOf ^op compositionQuantity ^dp
In Range Of	hasComposition ^op
Super Class Of	MatterComposition ^c ProductComposition ^c ProductObjectComposition ^c

Iso Compliance ^c

IRI	`http://w3id.org/CEON/ontology/product/ISOCompliance`
Sub Class Of	Compliance ^c

Item ^c

IRI	`http://w3id.org/CEON/ontology/product/Item`
Sub Class Of	resourceODP:PhysicalObject ^c
In Domain Of	hasProductObjectComponent ^op modelledBy ^op
In Range Of	associatedWithProductObject ^op hasProductObjectComponent ^op
Restriction	modelledBy ^op exactly 1 Item ^c

Manufacture Location ^c

IRI	`http://w3id.org/CEON/ontology/product/ManufactureLocation`
Sub Class Of	http://w3id.org/CEON/ontology/location/Location ^c
In Domain Of	countryOfManufacture ^dp
In Range Of	hasManufacturerLocation ^op
Restriction	http://w3id.org/CEON/ontology/location/hasCity ^dp max 1 ManufactureLocation ^c http://w3id.org/CEON/ontology/location/hasPostalCode ^dp max 1 ManufactureLocation ^c http://w3id.org/CEON/ontology/location/hasStreetAddress ^dp max 1 ManufactureLocation ^c countryOfManufacture ^dp max 1 ManufactureLocation ^c

Matter Composition ^c

IRI	`http://w3id.org/CEON/ontology/product/MatterComposition`
Sub Class Of	Composition ^c
In Domain Of	associatedWithMatter ^op
Restriction	associatedWithMatter ^op exactly 1 MatterComposition ^c

Origin Location ^c

IRI	`http://w3id.org/CEON/ontology/product/OriginLocation`
Sub Class Of	http://w3id.org/CEON/ontology/location/Location ^c
In Domain Of	countryOfOrigin ^dp
In Range Of	hasOriginLocation ^op
Restriction	http://w3id.org/CEON/ontology/location/hasCity ^dp max 1 OriginLocation ^c http://w3id.org/CEON/ontology/location/hasPostalCode ^dp max 1 OriginLocation ^c http://w3id.org/CEON/ontology/location/hasStreetAddress ^dp max 1 OriginLocation ^c countryOfOrigin ^dp max 1 OriginLocation ^c

Product ^c

IRI	`http://w3id.org/CEON/ontology/product/Product`
Is Defined By	ISO 59004:2024 -3.2.2 product
Sub Class Of	Solution ^c resourceODP:Resource
In Domain Of	hasProductComponent ^op
In Range Of	associatedWithProductModel ^op batchOfProduct ^op hasProductComponent ^op modelledBy ^op
Restriction	hasComposition ^op some Product ^c hasComposition ^op some Product ^c hasAssemblyLocation ^op only Product ^c hasManufacturerLocation ^op only Product ^c hasOriginLocation ^op only Product ^c

Product Composition ^c

IRI	`http://w3id.org/CEON/ontology/product/ProductComposition`
Sub Class Of	Composition ^c
In Domain Of	associatedWithProductModel ^op
Restriction	associatedWithProductModel ^op exactly 1 ProductComposition ^c

Product Object Composition ^c

IRI	`http://w3id.org/CEON/ontology/product/ProductObjectComposition`
Sub Class Of	Composition ^c
In Domain Of	associatedWithProductObject ^op
Restriction	associatedWithProductObject ^op exactly 1 ProductObjectComposition ^c

Production Location ^c

IRI	`http://w3id.org/CEON/ontology/product/ProductionLocation`
Sub Class Of	http://w3id.org/CEON/ontology/location/Location ^c
In Domain Of	countryOfProduction ^dp productionSite ^dp
Restriction	http://w3id.org/CEON/ontology/location/hasCity ^dp max 1 ProductionLocation ^c http://w3id.org/CEON/ontology/location/hasPostalCode ^dp max 1 ProductionLocation ^c http://w3id.org/CEON/ontology/location/hasStreetAddress ^dp max 1 ProductionLocation ^c countryOfProduction ^dp max 1 ProductionLocation ^c productionSite ^dp max 1 ProductionLocation ^c

Reach Compliance ^c

IRI	`http://w3id.org/CEON/ontology/product/REACHCompliance`
Sub Class Of	Compliance ^c
Equivalentclass	complianceWith ^op value REACH ^c

Regulation ^c

IRI	`http://w3id.org/CEON/ontology/product/Regulation`
Named Individuals	REACH ⁿⁱ RoHS ⁿⁱ

Ro Hs Compliance ^c

IRI	`http://w3id.org/CEON/ontology/product/RoHSCompliance`
Sub Class Of	Compliance ^c
Equivalentclass	complianceWith ^op value RoHS ^c

Solution ^c

IRI	`http://w3id.org/CEON/ontology/product/Solution`
Is Defined By	ISO 59004:2024 - 3.2.1 solution
Super Class Of	Product ^c

Supplier Location ^c

IRI	`http://w3id.org/CEON/ontology/product/SupplierLocation`
Sub Class Of	http://w3id.org/CEON/ontology/location/Location ^c

Batch Of Objects ^c

IRI	`http://w3id.org/CEON/ontology/resourceODP/BatchOfObjects`
In Domain Of	batchOfProduct ^op
Restriction	batchOfProduct ^op exactly 1 resourceODP:BatchOfObjects ^c

Matter ^c

IRI	`http://w3id.org/CEON/ontology/resourceODP/Matter`
In Range Of	associatedWithMatter ^op

Physical Object ^c

IRI	`http://w3id.org/CEON/ontology/resourceODP/PhysicalObject`
Super Class Of	Item ^c

Object Properties

has location ^op

IRI	`http://w3id.org/CEON/ontology/location/hasLocation`
Super Property Of	hasAssemblyLocation ^op hasManufacturerLocation ^op hasOriginLocation ^op

associated with matter ^op

IRI	`http://w3id.org/CEON/ontology/product/associatedWithMatter`
Domain	MatterComposition ^c
Range	resourceODP:Matter ^c

associated with product model ^op

IRI	`http://w3id.org/CEON/ontology/product/associatedWithProductModel`
Domain	ProductComposition ^c
Range	Product ^c

associated with product object ^op

IRI	`http://w3id.org/CEON/ontology/product/associatedWithProductObject`
Sub Property Of	topObjectProperty ^op
Domain	ProductObjectComposition ^c
Range	Item ^c

batch of product ^op

IRI	`http://w3id.org/CEON/ontology/product/batchOfProduct`
Domain	resourceODP:BatchOfObjects ^c
Range	Product ^c

compliance with ^op

IRI	`http://w3id.org/CEON/ontology/product/complianceWith`
Domain	Compliance ^c

composition of ^op

IRI	`http://w3id.org/CEON/ontology/product/compositionOf`
Domain	Composition ^c
Range	Product ^c or Item ^c or resourceODP:Matter ^c

has assembly location ^op

IRI	`http://w3id.org/CEON/ontology/product/hasAssemblyLocation`
Sub Property Of	http://w3id.org/CEON/ontology/location/hasLocation ^op
Domain	Item ^c or Product ^c
Range	AssemblyLocation ^c

has compliance ^op

IRI	`http://w3id.org/CEON/ontology/product/hasCompliance`
Domain	http://w3id.org/CEON/ontology/processODP/Process ^c or Item ^c or actorODP:Actor ^c or Product ^c
Range	Compliance ^c

has composition ^op

IRI	`http://w3id.org/CEON/ontology/product/hasComposition`
Domain	resourceODP:PhysicalObject ^c or Product ^c
Range	Composition ^c

has manufacturer location ^op

IRI	`http://w3id.org/CEON/ontology/product/hasManufacturerLocation`
Sub Property Of	http://w3id.org/CEON/ontology/location/hasLocation ^op
Domain	Item ^c or Product ^c
Range	ManufactureLocation ^c

has origin location ^op

IRI	`http://w3id.org/CEON/ontology/product/hasOriginLocation`
Sub Property Of	http://w3id.org/CEON/ontology/location/hasLocation ^op
Domain	Item ^c or Product ^c
Range	OriginLocation ^c

has product component ^op

IRI	`http://w3id.org/CEON/ontology/product/hasProductComponent`
Domain	Product ^c
Range	Product ^c

has product object component ^op

IRI	`http://w3id.org/CEON/ontology/product/hasProductObjectComponent`
Domain	Item ^c
Range	Item ^c

modelled by ^op

IRI	`http://w3id.org/CEON/ontology/product/modelledBy`
Domain	Item ^c
Range	Product ^c

Item ^c Product ^c resourceODP:Matter ^c Item ^c Product ^c actorODP:Actor ^c http://w3id.org/CEON/ontology/processODP/Process ^c Item ^c Product ^c Product ^c resourceODP:PhysicalObject ^c Item ^c Product ^c Item ^c Product ^c

Datatype Properties

has city ^dp

IRI	`http://w3id.org/CEON/ontology/location/hasCity`
Sub Property Of	topDataProperty ^dp

has country ^dp

IRI	`http://w3id.org/CEON/ontology/location/hasCountry`
Super Property Of	countryOfAssembly ^dp countryOfManufacture ^dp countryOfOrigin ^dp countryOfProduction ^dp

has postal code ^dp

IRI	`http://w3id.org/CEON/ontology/location/hasPostalCode`
Sub Property Of	topDataProperty ^dp

has street address ^dp

IRI	`http://w3id.org/CEON/ontology/location/hasStreetAddress`
Sub Property Of	topDataProperty ^dp

composition quantity ^dp

IRI	`http://w3id.org/CEON/ontology/product/compositionQuantity`
Domain	Composition ^c
Range	xsd:double

country of assembly ^dp

IRI	`http://w3id.org/CEON/ontology/product/countryOfAssembly`
Sub Property Of	http://w3id.org/CEON/ontology/location/hasCountry ^dp
Domain	AssemblyLocation ^c
Range	xsd:string

country of manufacture ^dp

IRI	`http://w3id.org/CEON/ontology/product/countryOfManufacture`
Sub Property Of	http://w3id.org/CEON/ontology/location/hasCountry ^dp
Domain	ManufactureLocation ^c
Range	xsd:string

country of origin ^dp

IRI	`http://w3id.org/CEON/ontology/product/countryOfOrigin`
Sub Property Of	http://w3id.org/CEON/ontology/location/hasCountry ^dp
Domain	OriginLocation ^c
Range	xsd:string

country of production ^dp

IRI	`http://w3id.org/CEON/ontology/product/countryOfProduction`
Sub Property Of	http://w3id.org/CEON/ontology/location/hasCountry ^dp
Domain	ProductionLocation ^c
Range	xsd:string

has brand ^dp

IRI	`http://w3id.org/CEON/ontology/product/hasBrand`
Range	xsd:string

has certificate ^dp

IRI	`http://w3id.org/CEON/ontology/product/hasCertificate`
Domain	Compliance ^c

has global trade item number ^dp

IRI	`http://w3id.org/CEON/ontology/product/hasGlobalTradeItemNumber`
Range	xsd:string

has product name ^dp

IRI	`http://w3id.org/CEON/ontology/product/hasProductName`
Range	xsd:string

production site ^dp

IRI	`http://w3id.org/CEON/ontology/product/productionSite`
Domain	ProductionLocation ^c
Range	xsd:string

Namespaces

:: http://w3id.org/CEON/ontology/product/
actorODP: http://w3id.org/CEON/ontology/actorODP/
dcterms: http://purl.org/dc/terms/
odp: http://www.ontologydesignpatterns.org/schemas/cpannotationschema.owl#
owl: http://www.w3.org/2002/07/owl#
prov: http://www.w3.org/ns/prov#
rdf: http://www.w3.org/1999/02/22-rdf-syntax-ns#
rdfs: http://www.w3.org/2000/01/rdf-schema#
resourceODP: http://w3id.org/CEON/ontology/resourceODP/
vann: http://purl.org/vocab/vann/
xsd: http://www.w3.org/2001/XMLSchema#

Legend

^c	Classes
^op	Object Properties
^dp	Datatype Properties

Circular Economy Ontology Network (CEON) - Product Module

Metadata

Overview

Connections between Product module and Resource ODP

Classes

Actor c

Resource Relation c

Location c

Process c

Assembly Location c

Compliance c

Composition c

Iso Compliance c

Item c

Manufacture Location c

Matter Composition c

Origin Location c

Product c

Product Composition c

Product Object Composition c

Production Location c

Reach Compliance c

Regulation c

Ro Hs Compliance c

Solution c

Supplier Location c

Batch Of Objects c

Matter c

Physical Object c

Object Properties

has location op

associated with matter op

associated with product model op

associated with product object op

batch of product op

compliance with op

composition of op

has assembly location op

has compliance op

has composition op

has manufacturer location op

has origin location op

has product component op

has product object component op

modelled by op

Datatype Properties

has city dp

has country dp

has postal code dp

has street address dp

composition quantity dp

country of assembly dp

country of manufacture dp

country of origin dp

country of production dp

has brand dp

has certificate dp

has global trade item number dp

has product name dp

production site dp

Namespaces

Legend

Table of Contents

Metadata

Classes

Object Properties

Datatype Properties

Namespaces

Legend

Actor ^c

Resource Relation ^c

Location ^c

Process ^c

Assembly Location ^c

Compliance ^c

Composition ^c

Iso Compliance ^c

Item ^c

Manufacture Location ^c

Matter Composition ^c

Origin Location ^c

Product ^c

Product Composition ^c

Product Object Composition ^c

Production Location ^c

Reach Compliance ^c

Regulation ^c

Ro Hs Compliance ^c

Solution ^c

Supplier Location ^c

Batch Of Objects ^c

Matter ^c

Physical Object ^c

has location ^op

associated with matter ^op

associated with product model ^op

associated with product object ^op

batch of product ^op

compliance with ^op

composition of ^op

has assembly location ^op

has compliance ^op

has composition ^op

has manufacturer location ^op

has origin location ^op

has product component ^op

has product object component ^op

modelled by ^op

has city ^dp

has country ^dp

has postal code ^dp

has street address ^dp

composition quantity ^dp

country of assembly ^dp

country of manufacture ^dp

country of origin ^dp

country of production ^dp

has brand ^dp

has certificate ^dp

has global trade item number ^dp

has product name ^dp

production site ^dp
